15-45-3260
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings CGrid VT SMT Rcpt Tin 60Ckt
PDF
/
Inventory: 941
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Polymer
Technical
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Color Black
Number of Rows 2
Voltage - Rated 250V
Additional Feature TOP ENTRY
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 60
Orientation Vertical
Reach Compliance Code unknown
Current Rating 2.5A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.199 inch
Contact Gender Female
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Body Depth 0.34 inch
Contact Style SQ PIN-SKT
Contact Resistance 15mOhm
Insulation Resistance 1000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Number of Circuits 60
Dielectric Withstanding Voltage 1500VAC V
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Plating Thickness 150μin
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
