15-45-1311
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings Obsolete
PDF
/
Inventory: 3819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reach Compliance Code unknown
Current Rating 2.5A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.199 inch
Contact Gender FEMALE
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Body Depth 0.34 inch
Contact Style SQ PIN-SKT
Contact Resistance 15mOhm
Insulation Resistance 100000000Ohm
Body/Shell Style PLUG
Dielectric Withstanding Voltage 1500VAC V
PCB Contact Row Spacing 3.81 mm
Contact Pattern RECTANGULAR
Orientation Vertical
Total Number of Contacts 22
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature HIGH PROFILE
Voltage - Rated 250V
Number of Rows 2
Color Black
Number of Positions 22
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Published 2004
Dimensions
Height 8.64mm
Length 27.9mm
Width 5.06mm
Plating Thickness 150μin
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Bronze
