15-45-0917
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings Obsolete
PDF
/
Inventory: 6444
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 75μin
Width 5.06mm
Length 43.2mm
Height 6.35mm
Technical
Contact Pattern RECTANGULAR
Body/Shell Style PLUG
Insulation Resistance 100000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Body Breadth 0.199 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2.5A
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 34
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature TOP ENTRY
Voltage - Rated 250V
Number of Rows 2
Color Black
Number of Positions 34
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Physical
Housing Material Plastic
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Bronze
