15-44-3626
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings Obsolete
PDF
/
Inventory: 2775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Rated 250V
Additional Feature POLARIZED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 26
Number of Rows 2
Color Black
Number of Positions 52
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Contact Pattern RECTANGULAR
Body/Shell Style PLUG
Insulation Resistance 100000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Body Breadth 0.199 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2.5A
Reach Compliance Code unknown
Orientation Vertical
Physical
Housing Material Plastic
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 15μin
Width 5.06mm
Length 66mm
Height 6.35mm
