15-24-7240

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 24POS 4.2MM VERT TIN
PDF
/
Buying Options
Total Price: USD $2.63
Unit Price: USD $2.62675
≥1 USD $2.62675
≥10 USD $2.15555
≥100 USD $2.0881
≥500 USD $2.02065
≥1000 USD $1.9532
Inventory: 2271
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Contact Material Brass
Contact Plating Tin
Mount Through Hole
Shell Material POLYAMIDE66
Housing Material Nylon

Technical

Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 2
Gender Receptacle
Additional Feature MINI-FIT BMI
HTS Code 8536.69.40.30
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.2mm
Orientation Vertical
Depth 9.6mm
Current Rating 9A
Number of Conductors ONE
Reference Standard UL
Voltage - Rated AC 600V
Reliability COMMERCIAL
Row Spacing - Mating 4.191 mm
Number of Contacts 24
Body Breadth 0.378 inch
Empty Shell NO
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Number of Ports 1
Max Voltage Rating (DC) 600.6kV
Withdrawl Force-Min .5004 N
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant

Dimensions

Length 55.6mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
