0901522126
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 26 POS 2.54mm Solder RA Thru-Hole C-Grid III? Tube
PDF
/
Inventory: 8810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Post 40.0μin 1.02μm
Contact Finish Thickness - Mating 40.0μin 1.02μm
Length 33.02mm
Technical
Number of Circuits 20
Housing Color Black
Contact Finish - Post Tin
Number of Contacts 26
Contact Length - Post 0.114 2.90mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.230 5.85mm
Depth 8.5mm
Orientation Right Angle
Pitch 2.54mm
Current Rating (Amps) 3A
Contact Type Female Socket
Contact Finish - Mating Tin
Fastening Type Push-Pull
Voltage - Rated 350V
Number of Rows 2
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 26
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series C-Grid III 90152
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Housing Material Polyester
Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Tin
Contact Material Phosphor Bronze
