0901512114
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 14 POS 2.54mm Solder ST Thru-Hole C-Grid? Tube
PDF
/
Buying Options
Total Price: USD $3.73
Unit Price: USD $3.7312
≥1 USD $3.7312
≥10 USD $3.28504
≥100 USD $2.629
Inventory: 2123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled
Technical
Operating Temperature -55°C~105°C
Packaging Tube
Series C-Grid III 90151
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 14
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Number of Rows 2
Voltage - Rated 350V
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Female Socket
Current Rating (Amps) 3A
Insulation Height 0.335 8.51mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.114 2.90mm
Dimensions
Contact Finish Thickness - Mating 40.0μin 1.02μm
Contact Finish Thickness - Post 40.0μin 1.02μm
Compliance
RoHS Status ROHS3 Compliant
