09-62-3102
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 10POS 0.156 GOLD PCB
PDF
/
Inventory: 7235
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Housing Material Nylon
Technical
Published 2008
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Max Operating Temperature 75°C
Min Operating Temperature 0°C
Color White
Number of Rows 1
Gender Receptacle
Voltage - Rated 250V
Additional Feature BOTTOM ENTRY
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Current Rating 5A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 10
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.25 inch
Contact Gender Female
UL Flammability Code 94V-2
Lead Length 4.06mm
Body Depth 0.45 inch
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Dimensions
Height 11.4mm
Length 39.5mm
Width 6.35mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
