09-52-3071

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RECEPT 7POS .156 R/A PCB
PDF
/
Inventory: 9717
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height 6.35mm

Technical

Lead Length 3.68mm
UL Flammability Code 94V-2
Contact Gender Female
Number of Contacts 7
Current Rating 4.5A
Orientation Right Angle
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Ramp
Additional Feature POLARIZED
Voltage - Rated 250V
Number of Rows 1
Color White
Connector Type Receptacle, Socket
Termination Solder
Pbfree Code yes
Published 2009

Physical

Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass

Supply Chain

Factory Lead Time 11 Weeks
