09-48-3036
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Header Connector, PCB Mount, RECEPT, 3 Contacts, SKT, 0.156 Pitch, PC TAIL Terminal, POLARIZED LCK
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.741649
≥1 USD $0.741649
≥10 USD $0.699671
≥100 USD $0.660064
≥500 USD $0.622702
≥1000 USD $0.587451
Inventory: 9578
Minimum: 1
-
+
Technical Details
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Housing Material Polyester
Technical
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 3
Max Operating Temperature 75°C
Min Operating Temperature 0°C
Color White
Number of Rows 1
Voltage - Rated 250V
Additional Feature KK, TOP ENTRY, STACKED
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Total Number of Contacts 3
Orientation Right Angle, Vertical
Current Rating 5A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.464 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.467 inch
Contact Gender Female
UL Flammability Code 94V-0
Body Depth 0.45 inch
Rated Current (Signal) 5A
Contact Style BELLOWED TYPE
Contact Resistance 6mOhm
Insulation Resistance 50000000000Ohm
Contact Pattern RECTANGULAR
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
