0873813863
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 38 POS 2mm Solder ST SMD Milli-Grid? Tube
PDF
/
Inventory: 8183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Contact Shape Square
Housing Material Thermoplastic
Technical
Operating Temperature -55°C~105°C
Packaging Tube
Series Milli-Grid 87381
Feature Pick and Place
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 38
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Applications Automotive, General Purpose, Telecommunications
Number of Rows 2
Voltage - Rated 125V
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 1.9A
Pitch 2mm
Orientation Vertical
Depth 6.2mm
Insulation Height 0.177 4.50mm
Style Board to Board
Number of Positions Loaded All
Current Rating 1.9A
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Row Spacing - Mating 0.079 (2.00mm)
Number of Contacts 38
Contact Finish - Post Tin
Housing Color Black
Number of Circuits 38
Dimensions
Length 38mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
