0448120023
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECPT 5POS .100" 15GOLD PCB
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.337582
≥1 USD $3.337582
≥10 USD $3.148661
≥100 USD $2.970433
≥500 USD $2.802297
≥1000 USD $2.643678
Inventory: 4952
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Brass Alloy
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series KK 44812
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Bottom or Top Entry
Number of Positions 5
Applications Automotive, General Purpose, Medical, Telecommunications
Number of Rows 1
Voltage - Rated 250VAC 176VDC
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Female Socket
Insulation Height 0.177 4.50mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Contact Length - Post 0.136 3.46mm
Contact Finish - Post Tin
Dimensions
Contact Finish Thickness - Mating 15.0μin 0.38μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
