0444750621

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Conn Power RCP 6 POS 4.2mm Solder ST Thru-Hole 6 Terminal 1 Port Mini-Fit? HCS Tray
PDF
/
Inventory: 2510
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA66), Nylon 6/6
Housing Material Nylon

Technical

Operating Temperature -40°C~105°C
Packaging Tray
Series Mini-Fit HCS 44475
Feature Board Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Rows 2
Voltage - Rated 600VAC
Fastening Type Push-Pull
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation Vertical
Depth 9.6mm
Insulation Height 0.446 11.33mm
Style Board to Board or Cable
Number of Positions Loaded All
Current Rating 11A
Pitch - Mating 0.165 4.20mm
Insulation Color Natural
Row Spacing - Mating 0.165 (4.20mm)
Contact Length - Post 0.138 3.50mm
Number of Contacts 6
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 1

Dimensions

Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Stack Height (Mating) 10.9mm 15.24mm 15.82mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
