0038001332
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.748
≥1 USD $0.748
≥10 USD $0.62216
≥100 USD $0.51876
≥500 USD $0.376138
≥1000 USD $0.345013
≥3000 USD $0.337225
Inventory: 7254
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Board Edge, Through Hole, Right Angle
Contact Shape Square
Insulation Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series KK 4455
Feature Board Hooks
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 2
Applications Automotive, General Purpose, Medical, Telecommunications
Number of Rows 1
Voltage - Rated 250VAC
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Non-Gendered
Current Rating (Amps) 4A
Insulation Height 0.185 4.70mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color White
Contact Length - Post 0.132 3.35mm
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
