0022027163
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 16 POS 2.54mm Solder ST Thru-Hole KK? Tray
PDF
/
Inventory: 4810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA), Nylon
Housing Material Nylon
Technical
Operating Temperature -40°C~80°C
Packaging Tray
Series KK 4455
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 16
Applications Automotive, General Purpose, Medical, Telecommunications
Number of Rows 1
Gender Female
Voltage - Rated 250VAC
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Non-Gendered
Orientation Vertical
Depth 7.7mm
Insulation Height 0.311 7.90mm
Style Board to Board or Cable
Number of Positions Loaded All
Current Rating 2.5A
Pitch - Mating 0.100 2.54mm
Contact Length - Post 0.132 3.35mm
Housing Color White
Contact Resistance 20mOhm
Number of Circuits 15
Dimensions
Length 40.54mm
Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
