0010101061

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 6POS 0.2 TIN EDGE MNT
PDF
/
Inventory: 3111
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Board Edge, Through Hole, Right Angle
Contact Shape Square
Insulation Material Polyamide (PA), Nylon

Technical

Operating Temperature -40°C~105°C
Packaging Bag
Series KK 3002
Feature Board Hooks
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 6
Applications Automotive, General Purpose, Medical, Telecommunications
Number of Rows 1
Voltage - Rated 250V
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Non-Gendered
Current Rating (Amps) 5A
Insulation Height 0.236 6.00mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.200 5.08mm
Insulation Color Natural
Contact Length - Post 0.170 4.32mm

Dimensions

Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm

Compliance

Material Flammability Rating UL94 V-2
RoHS Status ROHS3 Compliant
