803-41-082-61-001000

Mill-Max Manufacturing Corp.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 82POS 0.1 GOLD PCB
PDF
/
Inventory: 3843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm

Technical

Contact Finish - Post Tin
Contact Length - Post 0.104 2.64mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.276 7.00mm
Current Rating (Amps) 4.5A
Contact Type Female Socket
Contact Finish - Mating Gold
Fastening Type Push-Pull
Number of Rows 2
Number of Positions 82
Connector Type Receptacle
Termination Press-Fit, Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 803
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Contact Shape Circular
Mounting Type Through Hole
Contact Material Beryllium Copper

Supply Chain

Factory Lead Time 3 Weeks
