192991-0253
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Inventory: 7202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Orientation Straight
Terminal Pitch 5.08mm
Insulation Height 0.531 13.50mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.200 5.08mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.838 inch
Row Spacing - Mating 0.200 (5.08mm)
Contact Length - Post 0.224 5.70mm
Number Of PCB Rows 6
Body Breadth 1.795 inch
Body Depth 0.531 inch
Rated Current (Signal) 13A
Insulation Resistance 5000000000Ohm
Mating Contact Pitch 0.2 inch
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 5.08 mm
Contact Type Female Socket
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Holder
Gender Male
Number of Rows 4
Applications Automotive, General Purpose
Number of Positions 24
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Feature Mounting Flange
JESD-609 Code e4
Series Trident Rectangular
Packaging Bulk
Operating Temperature -40°C~105°C
Dimensions
Plating Thickness FLASH inch
Contact Finish Thickness - Mating 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Physical
Insulation Material Polyamide (PA), Nylon
Contact Shape Circular
Mounting Type Through Hole
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 5 Weeks
