A3C-28DA-2DSA
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 2881
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polybutylene Terephthalate (PBT)
Housing Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Bulk
Published 2004
Series A3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 28
Applications General Purpose, Telecommunications
Number of Rows 2
Gender Female
Voltage - Rated 200VAC
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 1A
Insulation Height 0.165 4.20mm
Style Board to Board or Cable
Number of Positions Loaded All
Reach Compliance Code unknown
Pitch - Mating 0.079 2.00mm
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.118 3.00mm
Lead Pitch 2mm
Contact Finish - Post Tin
Housing Color Black
Dimensions
Contact Finish Thickness - Mating 8.00μin 0.203μm
Contact Finish Thickness - Post 39.4μin 1.00μm
Stack Height (Mating) 5.1mm 6mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
