M80-8940305
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
POLARIZED SHROUDED Rectangular Connector Receptacle
PDF
/
Inventory: 6633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 52 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Contact Shape Circular
Insulation Material Polyester, Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Datamate L-Tek
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 3
Applications Automotive, General Purpose, Military
Number of Rows 1
Voltage - Rated 120V
Additional Feature POLARIZED, SHROUDED
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Terminal Pitch 2mm
Insulation Height 0.202 5.14mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Contact Length - Post 0.051 1.30mm
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.202 inch
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED KEY
Durability 500 Cycles
Insertion Force-Max 2.78 N
Dimensions
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Stack Height (Mating) 7.23mm 7.83mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
