M80-8873405
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 34POS 0.079 GOLD PCB
PDF
/
Buying Options
Total Price: USD $15.73
Unit Price: USD $15.7344
≥1 USD $15.7344
≥10 USD $13.63487
≥100 USD $11.237512
≥500 USD $10.263625
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 7.23mm 7.85mm
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 12.0μin 0.30μm
Plating Thickness 11μin
Length 37.15mm
Technical
Withdrawl Force-Min .1946 N
Durability 500 Cycles
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
Contact Resistance 25mOhm
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Contact Length - Post 0.118 3.00mm
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Current Rating 3A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.202 5.14mm
Depth 5.45mm
Orientation Straight
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Additional Feature POLARISED
Voltage - Rated 800V
Number of Rows 2
Applications Automotive, General Purpose, Military
Number of Positions 34
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Datamate L-Tek
Published 2011
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polyester
Insulation Material Polyester, Glass Filled
Contact Shape Circular
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 12 Weeks
