M80-8500445
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 2+2 POS DIL FEMALE VERT GOLD
PDF
/
Inventory: 6925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 7.23mm 7.85mm
Length - Termination 0.118 inch
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 12.0μin 0.30μm
Technical
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
Rated Current (Signal) 3A
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Contact Length - Post 0.118 3.00mm
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Current Rating 3A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.202 5.14mm
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Additional Feature POLARISED
Voltage - Rated 800V
Number of Rows 2
Applications Automotive, General Purpose, Military
Number of Positions 4
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Datamate L-Tek
Published 2013
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Thermoplastic
Insulation Material Polyamide (PA46), Nylon 4/6, Glass Filled
Contact Shape Circular
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
