M80-4S14605FC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 9275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Circular
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 46
Applications Automotive, General Purpose, Military
Number of Rows 2
Voltage - Rated 800V
Fastening Type Screw Lock
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 2.2A
Insulation Height 0.220 5.60mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Row Spacing - Mating 0.079 (2.00mm)
Dimensions
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Stack Height (Mating) 7.3mm 7.55mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
