M80-4060642
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 3+3 WAY FEMALE 4.5MM PC TAIL+REV FIX J/S
PDF
/
Buying Options
Total Price: USD $16
Unit Price: USD $15.9984
≥1 USD $15.9984
≥10 USD $13.8644
≥100 USD $11.426879
≥500 USD $10.436527
Inventory: 82
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Beryllium Copper
Mount Through Hole
Mounting Type Through Hole
Contact Shape Circular
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2013
Series Datamate J-Tek
JESD-609 Code e3
Feature Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 6
Applications Automotive, General Purpose, Military
Number of Rows 2
Voltage - Rated 800V
Additional Feature PANEL MOUNTABLE
Fastening Type Screw Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Insulation Height 0.204 5.17mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.185 4.70mm
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Contact Gender Female
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.079 inch
Durability 500 Cycles
Dimensions
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 137.8μin 3.50μm
Length - Termination 0.181 inch
Stack Height (Mating) 7.3mm 7.55mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
