M80-4024201
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 21+21 WAY FEMALE SMT + J/S
PDF
/
Inventory: 8721
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 137.8μin 3.50μm
Stack Height (Mating) 7.7mm 7.95mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Technical
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.079 inch
Insulation Resistance 100000000Ohm
Rated Current (Signal) 3A
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin-Lead
Number Of PCB Rows 2
Row Spacing - Mating 0.079 (2.00mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Reach Compliance Code not_compliant
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.220 5.60mm
Total Number of Contacts 42
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Voltage - Rated 120V
Number of Rows 2
Applications Automotive, General Purpose, Military
Number of Positions 42
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
JESD-609 Code e0
Series Datamate J-Tek
Published 2009
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Contact Shape Circular
Mounting Type Surface Mount
Contact Material Beryllium Copper
