M80-4021805
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
PANEL MOUNTABLE Rectangular Connector Receptacle
PDF
/
Inventory: 4632
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Circular
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 18
Applications Automotive, General Purpose, Military
Number of Rows 2
Voltage - Rated 120V
Additional Feature PANEL MOUNTABLE
HTS Code 8536.69.40.40
Fastening Type Screw Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Total Number of Contacts 18
Insulation Height 0.220 5.60mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 0.079 (2.00mm)
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Rated Current (Signal) 3A
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED HOUSING
Durability 500 Cycles
Dimensions
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Stack Height (Mating) 7.7mm 7.98mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
