M52-5154845
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
ROHS COMPLIANT Rectangular Connector Female Socket
PDF
/
Inventory: 2215
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series Archer M52
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 96
Applications General Purpose, Medical, Telecommunications
Number of Rows 2
Additional Feature ROHS COMPLIANT
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Current Rating (Amps) 1A
Total Number of Contacts 48
Insulation Height 0.224 5.69mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 0.100 (2.54mm)
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Body Breadth 0.197 inch
UL Flammability Code 94V-0
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.05 inch
Dielectric Withstanding Voltage 1400VAC V
PCB Contact Row Spacing 5.461 mm
Durability 300 Cycles
Withdrawl Force-Min .10008 N
Physical
Mounting Option 1 LOCKING
Insulation Material Polyamide (PA6T), Nylon 6T
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Dimensions
Stack Height (Mating) 8.5mm 9.77mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
