M20-7863642
RoHS
RoHS compliant
RoHS compliantPackage SIL
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
ROHS COMPLIANT Rectangular Connector Female Socket
PDF
/
Inventory: 8937
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 10.04mm 11.63mm
Technical
Withdrawl Force-Min .29746 N
Contact Resistance 20mOhm
Body Depth 0.295 inch
UL Flammability Code 94V-0
PCB Contact Pattern STAGGERED
Contact Finish - Post Tin
Number Of PCB Rows 2
Body Length or Diameter 3.608 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.295 7.50mm
Terminal Pitch 2.54mm
Total Number of Contacts 36
Current Rating (Amps) 3A
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature ROHS COMPLIANT
Number of Rows 1
Applications General Purpose
Number of Positions 36
Connector Type Receptacle, Bottom or Top Entry
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series M20
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Mounting Option 1 LOCKING
Insulation Material Polyamide (PA6T), Nylon 6T
Contact Shape Square
Package / Case SIL
Mounting Type Surface Mount
Contact Material Phosphor Bronze
