15210162601333
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Female Socket
PDF
/
Inventory: 959
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Gold
Mount Socket
Number of Pins 16
Housing Material Liquid Crystal Polymer
Technical
Part Status Active
Connector Type BOARD STACKING CONNECTOR
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Total Number of Contacts 16
Orientation Straight
Terminal Pitch 1.27mm
Current Rating 1.2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.6 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 125°C
Body Breadth 0.291 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Body Depth 0.246 inch
Contact Style SQ PIN-SKT
Contact Resistance 25mOhm
Insulation Resistance 10000000000Ohm
Mating Contact Pitch 0.05 inch
Termination Type SURFACE MOUNT
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 5.4864 mm
Durability 500 Cycles
Contact Finish Termination TIN
Contact Pattern RECTANGULAR
Insertion Force-Max .5004 N
Withdrawl Force-Min .5004 N
Mating Contact Row Spacing 0.053 inch
Insulator Color BLACK
Compliance
RoHS Status RoHS Compliant
