68682-327
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 2088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Polyphenylene
Technical
Packaging Tube
Series Dubox?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Bottom or Top Entry
Number of Positions 54
Color Black
Applications Automotive, General Purpose, Industrial, Telecommunications
Number of Rows 2
Voltage - Rated 1.5kV
Contact Finish - Mating Gold or Gold, GXT?
Contact Type Female Socket
Pitch 2.54mm
Orientation Straight
Depth 5.08mm
Insulation Height 0.276 7.00mm
Style Board to Board
Number of Positions Loaded All
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.118 3.00mm
Number of Contacts 54
Contact Finish - Post Tin
Housing Color Black
Dimensions
Length 69.01mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
