68046-628LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 4874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Contact Plating GXT, Gold
Mount Surface Mount
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Thermoplastic
Technical
Operating Temperature -65°C~125°C
Packaging Tube
Series Dubox?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 56
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Black
Applications Automotive, General Purpose, Industrial, Telecommunications
Number of Rows 2
Gender Female
Voltage - Rated 1000V
Fastening Type Push-Pull
Contact Finish - Mating Gold or Gold, GXT?
Contact Type Female Socket
Pitch 2.54mm
Orientation Straight
Depth 5.08mm
Insulation Height 0.310 7.87mm
Style Board to Board
Number of Positions Loaded All
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Number of Contacts 56
Contact Finish - Post Tin
Contact Gender Female
Housing Color Black
Contact Resistance 20mOhm
Max Voltage Rating (AC) 1kV
Dimensions
Length 71.55mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
