956214-2700-AR-PR

3M
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Headers & Wire Housings 14P THRU-BD SKT 2R STRT SMT 10U AU
PDF
/
Inventory: 5891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Shape Square
Insulation Material Thermoplastic
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Copper Alloy

Technical

Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2013
Series 956
Feature Pick and Place
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Bottom Entry
Number of Positions 14
Color Black
Number of Rows 2
Gender Female
Voltage - Rated 1000VDC
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 1A
Pitch 2.0066mm
Insulation Height 0.110 2.79mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Row Spacing - Mating 0.079 (2.00mm)
Contact Finish - Post Tin

Dimensions

Contact Finish Thickness - Mating Flash
Contact Finish Thickness - Post 40.0μin 1.02μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Supply Chain

Factory Lead Time 9 Weeks
