929975-01-14

3M
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 28POS 0.1 TIN-LEAD PCB
PDF
/
Buying Options
Total Price: USD $3.1
Unit Price: USD $3.0976
≥1 USD $3.0976
≥10 USD $2.81424
≥100 USD $2.169772
≥500 USD $1.797822
≥1000 USD $1.611843
Inventory: 361
Minimum: 1
-
+

Technical Details

Physical

Contact Material Copper Alloy
Contact Plating Lead, Tin
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Housing Material Polyester

Technical

Operating Temperature -40°C~105°C
Packaging Bulk
Published 2011
Series 929
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Receptacle
Number of Positions 28
Color Black
Number of Rows 2
Gender Female
Voltage - Rated 1500V
Fastening Type Push-Pull
Contact Finish - Mating Tin-Lead
Contact Type Forked
Current Rating (Amps) 2A
Pitch 2.54mm
Insulation Height 0.325 8.25mm
Style Board to Board
Number of Positions Loaded All
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.125 3.18mm
Number of Contacts 28
Contact Finish - Post Tin-Lead
Contact Gender Female
Housing Color Black

Dimensions

Height 8.26mm
Length 35.6mm
Width 5.08mm
Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
