929974-01-25-RK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT .100 SNGL STR 25POS
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.568386
≥1 USD $2.568386
≥10 USD $2.423002
≥100 USD $2.285854
≥500 USD $2.156463
≥1000 USD $2.034407
Inventory: 4965
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 100.0μin 2.54μm
Contact Finish Thickness - Mating 100.0μin 2.54μm
Width 2.54mm
Length 63.5mm
Height 8.26mm
Technical
Housing Color Black
Contact Finish - Post Tin
Number of Contacts 25
Contact Length - Post 0.125 3.18mm
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.325 8.25mm
Pitch 2.54mm
Current Rating (Amps) 2A
Contact Type Forked
Contact Finish - Mating Tin
Fastening Type Push-Pull
Voltage - Rated 1500V
Gender Female
Number of Rows 1
Color Black
Number of Positions 25
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series 929
Published 2009
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Housing Material Nylon
Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Copper Alloy
