929850-01-36-30

3M
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RCPT 36POS 0.1 GOLD PCB
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.3592
≥1 USD $5.3592
≥10 USD $4.84704
≥100 USD $4.244064
Inventory: 371
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 30.0μin 0.76μm
Width 2.54mm
Length 91.4mm
Height 8.26mm

Technical

Housing Color Black
Contact Gender Female
Contact Finish - Post Tin-Lead
Contact Length - Post 0.125 3.18mm
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.325 8.25mm
Pitch 2.54mm
Current Rating (Amps) 2A
Contact Type Forked
Contact Finish - Mating Gold
Fastening Type Push-Pull
Voltage - Rated 1500V
Gender Female
Number of Rows 1
Color Black
Number of Positions 36
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 929
Published 2009
Packaging Bulk
Operating Temperature -40°C~105°C

Physical

Housing Material Polyester
Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 4 Weeks
