6-104069-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings HDR 2X34P R/A T/H
PDF
/
Buying Options
Total Price: USD $26
Unit Price: USD $25.9952
≥1 USD $25.9952
≥10 USD $21.45968
≥100 USD $18.433184
Inventory: 237
Minimum: 1
-
+
Technical Details
Technical
Number of Contacts 68
Contact Finish - Post Tin
Contact Length - Mating 0.125 3.18mm
Housing Color Black
Lead Length 2.54mm
Operating Supply Voltage 30V
ELV Compliant
Max Voltage Rating (AC) 30V
Contact Current Rating 1A
Mating Post Length 2.54mm
Keyed No
Shrouding Shrouded - 2 Wall
Contact Length - Post 0.100 2.54mm
Row Spacing - Mating 0.100 (2.54mm)
Approval Agency CSA
Voltage - Rated AC 30V
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.290 7.37mm
Depth 13.72mm
Orientation Right Angle
Pitch 1.27mm
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Latch Holder
Voltage - Rated 30VAC
Gender Male
Number of Rows 2
Applications Automotive, General Purpose, Medical, Telecommunications
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 68
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Series AMPMODU System 50
Published 2005
Packaging Tube
Operating Temperature -65°C~105°C
Dimensions
Length 49.53mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 150.0μin 3.81μm
PCB Thickness 1.397mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Insulation Material Thermoplastic
Contact Shape Circular
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 7 Weeks
