1744056-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER R/A 3POS 3.96MM
PDF
/
Inventory: 7388
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Housing Material Polymer
PCB Mounting Orientation Right Angle
PCB Mount Retention Without
PCB Mount Alignment Without
Technical
Operating Temperature -25°C~105°C
Packaging Bulk
Published 2009
Series Economy Power
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 3
Max Operating Temperature 105°C
Min Operating Temperature -25°C
Color Natural
Applications General Purpose, Industrial, Lighting
Number of Rows 1
Voltage - Rated 250VAC
Fastening Type Friction Lock
Contact Finish - Mating Tin
Contact Type Male Pin
Current Rating (Amps) 7.5A
Pitch 3.9624mm
Orientation Right Angle
Insulation Height 0.339 8.61mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 8A
Pitch - Mating 0.156 3.96mm
Insulation Color Black
Contact Length - Post 0.142 3.60mm
Shrouding Shrouded - 1 Wall
Number of Contacts 3
Contact Finish - Post Tin
Contact Length - Mating 0.338 8.59mm
Housing Color Black
Operating Supply Voltage 250V
ELV Compliant
Plating Tin
Sealable No
Contact Current Rating 8A
Circuit Application Power
Mating Retention With
Mating Post Length 8.6mm
Dimensions
Height 8.2mm
Length 19.7993mm
Width 15.6718mm
Plating Thickness 800 nm
Contact Finish Thickness - Mating 120.0μin 3.05μm
Contact Finish Thickness - Post 120.0μin 3.05μm
Length - Tail 3.7mm
PCB Thickness 1.6002mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
