1734598-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 3POS 1.25MM VERT T/H
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.35992
≥100 USD $0.299596
≥500 USD $0.254637
≥1000 USD $0.223186
≥3000 USD $0.199223
Inventory: 6758
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Phosphor Bronze
Contact Plating Nickel, Tin
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyamide (PA9T), Nylon 9T, Glass Filled
Housing Material Thermoplastic
PCB Mount Retention Without
Technical
Operating Temperature -25°C~85°C
Packaging Tube
Published 2009
Series High Performance Interconnect (HPI)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header
Number of Positions 3
Applications Automotive, General Purpose, Industrial, Medical
Number of Rows 1
Voltage - Rated 100VAC
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Current Rating (Amps) 1A
Orientation Vertical
Depth 3.2mm
Insulation Height 0.185 4.70mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 800mA
Pitch - Mating 0.049 1.25mm
Insulation Color Natural
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Contact Length - Post 0.067 1.70mm
Shrouding Shrouded - 4 Wall
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Contact Gender Male
UL Flammability Code 94V-0
Lead Length 1.7018mm
Operating Supply Voltage 100V
Mating Contact Pitch 0.049 inch
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 28 AWG
Insertion Force-Max 9.7856 N
Contact Current Rating 800mA
Dimensions
Height 4.699mm
Length 5.4864mm
Width 3.2mm
Contact Finish Thickness - Mating 120.0μin 3.05μm
Length - Tail 1.7018mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
