1437254-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER R/A 18POS 2.54MM
PDF
/
Inventory: 2566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
PCB Thickness 2.79mm
Length - Tail 3.63mm
Contact Finish Thickness - Post 100.0μin 2.54μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 760 nm
Technical
Mating Connector Lock With
Mating Alignment With
Circuit Application Signal
Sealable No
Housing Color Blue
Contact Length - Mating 0.235 5.97mm
Contact Finish - Post Tin-Lead
Number of Contacts 16
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.143 3.63mm
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Blue
Pitch - Mating 0.100 2.54mm
Current Rating 2A
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.352 8.94mm
Orientation Right Angle
Pitch 2.54mm
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Latch Holder
Number of Rows 2
Color Blue
Number of Positions 18
Connector Type Header
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Keying Slot
Series FlexPac
Published 2008
Packaging Bulk
Physical
PCB Mounting Orientation Right Angle
Housing Material Nylon
Insulation Material Polyamide (PA), Nylon
Contact Shape Square
Mounting Type Through Hole, Right Angle
Contact Plating Gold
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 23 Weeks
