1-1969694-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER R/A 2POS 6MM
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2848
≥1 USD $1.2848
≥10 USD $1.17392
≥100 USD $1.046725
≥500 USD $1.029362
≥1000 USD $0.838534
≥3000 USD $0.774919
Inventory: 4838
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 44 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Copper Alloy
Mounting Type Through Hole, Right Angle
Contact Shape Rectangular
Insulation Material Polyamide (PA), Nylon
Housing Material Nylon
PCB Mounting Orientation Right Angle
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2016
Series Power Triple Lock
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Header
Applications General Purpose
Number of Rows 1
Voltage - Rated 600VAC
Fastening Type Latch Holder
Contact Finish - Mating Tin
Contact Type Male Pin
Current Rating (Amps) Varies by WireGAuge
Orientation Right Angle
Insulation Height 0.589 14.96mm
Style Board to Cable/Wire
Number of Positions Loaded All
Current Rating 19.5A
Pitch - Mating 0.236 6.00mm
Insulation Color Gray
Approval Agency VDE
Shrouding Shrouded - 4 Wall
Housing Color Grey
Operating Supply Voltage 600V
Sealable No
Contact Current Rating 19.5A
Circuit Application Power
Number of Power Positions 2
Contact Retention With
VDE Tested Yes
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
