9-2013519-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $5.13
Unit Price: USD $5.1304
≥1 USD $5.1304
≥10 USD $4.49167
≥100 USD $4.37419
≥500 USD $4.280056
≥1000 USD $4.021345
≥3000 USD $3.997858
Inventory: 2192
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
PCB Thickness 1.6002mm
Length - Tail 3.8mm
Width 20.9mm
Length 75.692mm
Height 13mm
Technical
VDE Tested No
Preloaded Yes
Mating Alignment With
Contact Retention Without
Contact Rating (Current) 14.5A
Mating Retention With
Halogen Free Halogen Free
Sealable No
ELV Compliant
Operating Supply Voltage 300V
Housing Color Black
Number of Contacts 7
Current Rating 14.5A
Shielding Unshielded
Orientation Right Angle
Pitch 7.493mm
Gender Male
Number of Rows 1
Number of Positions 10
Connector Type Header, Plug, Tab
Termination Solder
Physical
PCB Mount Retention With
PCB Mounting Orientation Right Angle
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
