9-1734508-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 6991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Gold
Contact Shape Square
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Termination Through Hole
Connector Type Header, Pin, Plug
Number of Positions 12
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 2
Pitch 2.0066mm
Orientation Vertical
Approval Agency UL
Row Spacing - Mating 2 mm
Housing Color Black
Lead Length 2.6mm
Insulation Resistance 1GOhm
ELV Compliant
Mating Post Length 4mm
Contact Rating (Current) 1A
Dimensions
Plating Thickness 2.54μm
PCB Thickness 1.57mm
Stack Height 1.4986mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
