87543-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 6596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Lead, Tin
Mount Through Hole
Housing Material Thermoplastic
Technical
Termination Solder
Connector Type Male Pin
Number of Positions 2
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON NI
Pitch 2.54mm
Total Number of Contacts 22
Orientation Vertical
Reach Compliance Code unknown
Number of Conductors ONE
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Contact Length - Mating 8.0772mm
PCB Contact Pattern RECTANGULAR
Body Depth 0.09 inch
Contact Style SQ PIN-SKT
ELV Non-Compliant
Contact Pattern RECTANGULAR
Dimensions
Height 2.29mm
Length 2.13mm
Width 5.08mm
Plating Thickness 100μin
Compliance
Flammability Rating UL94 V-0
Lead Free Contains Lead
