8-171825-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings E.I.S 3P POST ASSY RED (V)
PDF
/
Inventory: 1858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
Polarized No
Durability 25 Cycles
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 500000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Body Depth 0.409 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Contact Gender Male
Body Breadth 0.209 inch
Operating Temperature (Max) 95°C
Contact Length - Mating 7.493mm
Number of Contacts 3
Number Of PCB Rows 1
Body Length or Diameter 0.295 inch
Approval Agency UL
Reliability COMMERCIAL
Number of Conductors ONE
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Red
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
