794313-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Pin & Socket Connectors 24P DUAC PWR CONN ASY VT AU LF
PDF
/
Inventory: 2694
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.138 inch
Plating Thickness 30μin
Technical
Withdrawl Force-Min .5004 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
PCB Contact Row Spacing 5.5118 mm
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 1000000000Ohm
Rated Current (Signal) 9A
Body Depth 0.504 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.394 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 4.191 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 9A
Total Number of Contacts 24
Pitch 4.2mm
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Number of Rows 2
Color Natural
Number of Positions 24
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Nylon
Mount Through Hole
Contact Plating Gold
Contact Material COPPER ALLOY
