794176-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Power to the Board AMP DUAC/PL 12P HDR ASSY RA
PDF
/
Inventory: 8231
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.138 inch
Plating Thickness 30μin
Technical
Contact Rating (Current) 9A
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 5.5118 mm
Polarization Key POLAR PIN POSITION
ELV Compliant
Insulation Resistance 1000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 9A
Body Depth 0.764 inch
Empty Shell NO
Housing Color White
UL Flammability Code 94V-0
Body Breadth 0.515 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 1.433 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 9A
Orientation Right Angle
Total Number of Contacts 11
Pitch 4.191mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature AMP-DUAC/PL
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 12
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Packaging Bulk
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material PBT
Shell Material POLYBUTYLENE TEREPHTHALATE
Mounting Type BOARD
Contact Plating Gold
Contact Material Brass
