770971-1 image
Favorite
770971-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Power to the Board RA DUAL PIN HDR 10P 800
PDF
/
Inventory: 6643
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Brass
Contact Plating Lead, Tin
Mount Through Hole
Shell Material POLYAMIDE
Housing Material Nylon
PCB Mounting Orientation Right Angle

Technical

Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination Solder
Connector Type Pin
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color White
Number of Rows 2
Voltage - Rated 600V
Additional Feature MATE-N-LOK, POLARIZATION AVAILABLE
Fastening Type Ramp
Contact Finish - Mating TIN LEAD
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.1148mm
Orientation Right Angle
Current Rating 9.5A
Approval Agency CSA
Row Spacing - Mating 162 μm
Number of Contacts 10
Contact Gender Male
UL Flammability Code 94V-0
Empty Shell NO
Max Voltage Rating (AC) 600V
Number of Ports 1
Circuit Application Power
Contact Rating (Current) 9.5A
VDE Tested Yes

Dimensions

Height 11.86mm
Length 22.28mm
Width 12.7mm
Plating Thickness 150μm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
