644629-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
AMP Rectangular Connector Header
PDF
/
Inventory: 1552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Gold
Mount Through Hole
Contact Shape Square
Housing Material Polyester
PCB Mounting Orientation Right Angle
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination Solder
Connector Type Header, Pin, Plug
Number of Rows 1
Gender Male
Additional Feature AMP
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Orientation Right Angle
Current Rating 7A
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 600V
Reliability COMMERCIAL
Shrouding No
Number Of PCB Rows 1
Number of Contacts 3
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.425 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color White
Lead Length 3.18mm
Contact Style SQ PIN-SKT
Insulation Resistance 5000000Ohm
Body/Shell Style RECEPTACLE
ELV Compliant
Contact Pattern RECTANGULAR
Insulator Color NATURAL
Dimensions
Length - Termination 0.205 inch
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
