641209-5 image
Favorite
641209-5 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings HDR ASSY 5P
PDF
/
Inventory: 2194
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Gold
Mount Through Hole
Contact Shape Round
Housing Material Polyester
PCB Mounting Orientation Vertical
Underplate Material Nickel

Technical

Termination Solder
Connector Type Header, Pin, Plug
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 1
Voltage - Rated 600V
Additional Feature AMP
Fastening Type Friction
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Depth 7.67mm
Current Rating 7A
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 5
Contact Length - Mating 10.16mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-0
Housing Color Natural, White
Lead Length 3.18mm
Contact Resistance 3mOhm
ELV Compliant
Max Voltage Rating (AC) 600V
Mating Post Length 10.16mm
Contact Rating (Current) 7A

Dimensions

Height 10.795mm
Length 19.812mm
Plating Thickness 760 nm
Length - Tail 3.18mm
PCB Thickness 1.6002mm

Compliance

RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
