582843-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Standard Card Edge Connectors 47 AMP BLADE HDR ASSM/MIL
PDF
/
Inventory: 3527
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Metal
Contact Plating Gold
Mount Through Hole
PCB Mounting Orientation Right Angle
Technical
Packaging Bulk
Pbfree Code no
Termination Solder
Connector Type BOARD CONNECTOR
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Green
Number of Rows 2
Gender Male
Additional Feature STAGGERED CONFIGURATION
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 21.84mm
Military Standard MIL-DTL-21097
Row Spacing - Mating 3.175 mm
Number of Contacts 47
Mating Information MULTIPLE MATING PARTS AVAILABLE
Lead Length 3.05mm
Contact Resistance 25mOhm
ELV Non-Compliant
Preloaded Yes
Dimensions
Length 142.82mm
PCB Thickness 1.6002mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
